Rohs Mutilayer 6 Layer Circuit Boards 1OZ All Layers Red Soldermask PCB HASL/ENIG
Linked Electronics Co., Limited provides you the best quality and most competitive price for printed circuit board(PCB) fabrication and PCB assembly.
PCB Board stands for "Printed Circuit Board." A PCB board is a thin subtrate which is made of fiberglass, composite epoxy, or other laminate material. Conductive pathways are etched onto the board, connecting different components on the bare PCB board, such as transistors, capacitors, resistors, and other ICs
Classification of PCB Board by types.
There are several types of PCB boards each with their own particular manufacturing specifications, material and applications. There are Single-sided PCBs, Double-sided PCBs, Multi-layer PCBs, FR4 Rigid PCBs, Flexible PCBs( FPC), Rigid-Flex PCBs, High-frequency PCBs, Aluminum-backed PCBs.
Two Layer PCB Board Definition
2 Layer PCB board is PCB that has 2 conductive layers.Vias in 2 layer PCB are used to create electrical connections that enable the routing of the traces so that they reach the opposite side of the board
Mutilayer PCB Board Definition
Multilayer PCB Board is a PCB that is made with three or more conductive copper foil layers. These appear as several layers of 2 layer printed circuit boards. The 4 layer PCB design involves a prepreg layer that laminated together, that is bond different double-sided boards together by applying heat and pressure.
| Number of Layers | 6 Layer |
| Material | FR-4 |
| Board Thickness | 64mil +/-10% |
| Copper Thickness | 35um all layers/1oz all layers |
| Surface Finish | HASL Rohs |
| Soldmask & Silkscreen | Dark Green |
| Quality Standard | IPC-A-610D, IPC Class 2, Flying Probe or fixture |
| Lead Time | 2 working days |
Linked Electronics has invested in the best equipment for production and staff training never stop at our facility. We have a production capability for standard and HDI, Rigid, RF and high frequency PCBs, together with through hole and min 0201 chips, 0.2mm pitch BGA balls SMD soldering, in small batch, mid volume and high volume quantities.
1.Drilling workshop | 4 drilling bits of drilling machine: 4 sets 2 drilling bits of drilling machine: 2 sets |
2. photo plotting workshop | Israel “ORBOTECH” Photo Plotters |
3.AOI | AOI machine |
4.IPQC | “OXFORD” CMI 700 Copper Thickness Tester |
5.Impedance test | USA “Tektronix” DSA 8200 Impedance Tester |
| 6.Outline workshop | CNC routing machine: 7 sets angle-cutting machine V-cut machine |
| 7.Testing Workshop | Surpass X-600: 2sets WTD FT-2808: 5sets WTD HV300: 1set |
8.X-ray | X-ray machine |
|
|
